MX-1 SHAPER CUTTER
Hybrid composition ,chipping resistance as Powder HSS and wear resistance as Dissolution HSS are altogether.
HSS = High Speed Steel.
Applications
| Work piece | Module 1.3 PA30° SPUR NT30 Carburized steel |
|---|---|
| Cutter | Outer dia. 30mm NT20 MX-1 with SuperDry PVD COAT |
| Cutting Conditions | Strokes 850/920 str/min Circumference feed 1.5/0.50 mm/str Radius feed 0.020/0.012 mm/str |
