55R series

companies handling the product：Nidec Corporation

This is inner rotor type brushless DC motor, with long life, high out-put and high efficiency.

It is an in-wheel motor used for electric assist bicycles. With a speed reducer, low cogging and high torque.

characteristics:
Low noise,Low vibration,Energy saving,Long life,Stability,RoHs support
Contact information for product inquiry
Contact us

Product data

Basic information

sort by power source type DC
Size φ86
Length 168 mm～
Operation temperature 0～50 ℃
Mass 1900～2300 g
Companies handling the product Nidec Corporation
Input
Operating voltage 24 V24~24 V
Operating current 7.8 A7.8~7.8 A
Output
output 140 W140~140 W
torque 7700 mN・m7700~7700 mN・m
Rpm 175 min-1175~175 min-1
No-load rpm 200 min-1200~200 min-1
Momentary maximum torque 35 mN・m35~35 mN・m
Instantaneous maximum allowable rpm 80 min-180~80 min-1

IC with 3-hall senser_clear IP64 regulation_with a speed reducer.
