Small-size and precision motors｜Brushless DC motors｜Motor
Smart_20N series
companies handling the product：Nidec Corporation
The brushless motor ensures long life and high efficiency.
In major central heating and air conditioner manufacturers in North America and Europe, this is used in motors to control dampers used in adjusting temperatures between rooms, and in those linked to fire and smoke detection. In addition to use in building air conditioning, this motor may also be used for driving gears, pumps, and pulleys. Customization in line with customer requirements enables changes to base plate configuration, addition of pinion gears, changing of shaft projection direction, and built-in drive circuits. Please contact us for details.
- characteristics:
- Low noise,Low vibration,Energy saving,Long life,Stability,Enviromental performance,RoHs support
- Contact information for product inquiry
- Contact Us
Product data
Basic information
| sort by power source type | DC |
|---|---|
| Size | φ25 |
| Length | 13 mm～ |
| Mass | 25～30 g |
| Companies handling the product | Nidec Corporation |
| Operating voltage | 5~24 V |
|---|---|
| Operating current | ~0.3 A |
| output | ~1.1 W |
|---|---|
| torque | ~9.7 mN・m |
| Stall torque | 15.2~15.2 mN・m |
| Rpm | 1000~ min-1 |
| No-load rpm | 3000~3000 min-1 |
| Momentary maximum torque | 15.2~15.2 mN・m |
| Instantaneous maximum allowable rpm | 3000~3000 min-1 |
Instantaneous maximum allowable rpm
